CR36 Crane
Specifications for CR36 Crane
Crane link | (BR0) Without brake or (BR2) Double brake |
Grapple | (C0) Without grapple or (C16) Grapple for logs 0,16 m2 (FL) or (C18) Grapple for logs 0,18 m2 (FL) |
Supply of Hydraulics | Constant Flow hydraulic or Load Sensing hydraulic |
Control Unit | (A0) Without control valve or (A4) 4/8 XY+2x el.on-off valve, Hydro-Control D3M, 190bar or (A7) 4/8 XYZ control valve, Hydro-Control, 190bar, (215 bar by request) |
Crane Base | (B0) Without support legs or (B1) Support legs small FD type or (B2.1) Support legs A type small, including 3-point connection (only available for FT9) |
Accessories | No accessories or (W1) Winch 1400 with radio control (winch valve integrated to A11-A41) or (W0) Main boom ready for winch |
Valve block cover bag (for A4, A4.2, A7, A11, A12 valves) | No valve block cover or (VBC) Valve block cover |
Protection Sleeves for Hoses | (PSH) Protection sleeves for hoses |
