CR47 Crane

Login to view Price


Specifications for CR47 Crane

Crane link (BR0) Without brake or (BR2) Double brake
Grapple (C0) Without grapple or (C16) Grapple for logs 0,16 m2 (FL) or (C18) Grapple for logs 0,18 m2 (FL) or (C23) Grapple for logs 0,23 m2 (FL) or (C36) Grapple for energy wood 0,21 m2 (FL) or (GB23) Gravel bucket for C23 grapple 0,24 m3
Supply of Hydraulics Constant Flow hydraulic or Load Sensing hydraulic
Control Unit (A0) Without control valve or (A4) 4/8 XY+2x el.on-off valve, Hydro-Control D3M, 190bar or (A7) 4/8 XYZ control valve, Hydro-Control, 190bar, (215 bar by request) or (A11) 2/8 Pre-hydraulic,+2x el.propo, Parker P70, 215bar or (A12) 2/8 Pre-hydraulic,+2x el.propo, Walvoil DPX100, (max 120L/min) 215bar or (AH020.38) El. propo, Parker L90 valve block, 215 bar without Joysticks and control set or (AH23.38) El. propo, Parker L90 valve block, Parker MC43 controller, 215 bar with Parker IQAN LC6 Joysticks with CAN modules, 2 x cable set (LS compatible, speeds and ramps not adjustable by customer) or (AH26.38) Radio control IMET and Parker L90 valve block, 215 bar or (AH23.38BT) El. propo, Parker L90 valve block, Parker MC43 controller, 215 bar with Parker IQAN LC6 Joysticks with CAN modules, Parker G11 bluetooth dongle, 2 x cable set (LS compatible, speeds and ramps adjustable via Parker free IQANGO app)
Crane Base (BFF) Farmi A-type Support Legs 3PL or (B0) Without support legs or (BF1) Support legs CR47-CR69+ Flap down type
Accessories No accessories or (W1) Winch 1400 with radio control (winch valve integrated to A11-A41) or (W0) Main boom ready for winch
Protection Sleeves for Hoses Valves A2-A7- 1,0 m standard Hose Covers or (No PSH) Valves A11-AH26.38 or (PSH) Only trailers with Operator stand - Long Hose Covers
