FT11 Trailer (M26)

Login to view Price


Specifications for FT11 Trailer (M26)

Cargo Module (A3+BL) Bolsters 3 pairs + bolster lock or (A4+BL) Bolsters 4 pairs + bolster lock or (A4Ex+BL) Frame extension, bolsters 4 pairs+bolster lock
Drawbar (C2) German high or (C3) Austrian low
Hitch (K1) Bolted, swivelling D50 (100x110) or (K1.1) Bolted HD, swiveling D50 (110x100) or (K2) Bolted, fixed D40 (100x110) or (K3) Bolted K-80 (100x110)
Drive (RWD0) Without drive or (RWD) Roller-drive, tractor hydraulic or (RWD+) Roller-drive with elect. control system or (25WDF) Front 2WD BB250 el. control or (25WDR) Rear 2WD BB250 el. control
Brakes (B0) unbraked or (B1) Hydraulic, 2 hubs or (B2) Hydraulic, 4 hubs or (B3) Air, 2 hubs or (B4) Air, 4 hubs
Parking brake No or (PB1) Actuators at wheels
Hydraulic supply Tractor hydraulics or (P1+T2+) Piston pump on the drawbar, 65L @650rpm, Tank, 95L oil-filled with HVLP oil or (P2+T2+) Piston pump on the drawbar, 82L @650rpm, Tank, 95L oil-filled with HVLP oil or (P4+T2+) Piston pump with multiplier on the drawbar, 98L @650rpm, Tank, 95L oil-filled with HVLP oil or (P6+T2+) Load sensing pump with multiplier on the drawbar, 120L @650rpm, Tank, 95L oil-filled with HVLP oil or (P4PTO+T2+) Piston pump with female-multiplier to PTO, 98L @650rpm, Tank, 95L oil-filled with HVLP oil or (P6PTO+T2+) Load sensing pump with female-multiplier to PTO, 98L @650rpm, Tank, 95L oil-filled with HVLP oil
Oil cooling package (CP0) No or (CP2) Yes, on T2 or T2+
Operator platform (D0) No platform or (D1) Platform with back support
Wheels (WH0) w/o wheels or (WH3.6) 500/50-17 RF-rim, 6 holes or (WH5.6) 400/55-22,5 RF-rim, 6 holes or (WH6.8) 550/45-22,5 RF-rim, 8 holes or (WH8.8) 500/45-22,5 RF-rim, 8 holes
