FT9 Trailer
Specifications for FT9 Trailer
Cargo Module | (A3+BL) Bolsters 3 pairs + bolster lock or (A4+BL) Bolsters 4 pairs + bolster lock or (A4Ex+BL) Frame extension, bolsters 4 pairs+bolster lock |
Coupling | (C1) Scandinavian low type drawbar with welded swiveling hitch or (C2) German high type drawbar without hitch or (C3) Austrian low type drawbar without hitch or (C7) High type overrun drawbar with hitch, cables and Rückmatic+B1 brakes (option B1-C7) |
Wheel set | (WH2.6e) Wheels 400/60-15,5 RF-rim, 6 holes, Starco or (WH3.6_ET-70) Wheels 500/50-17 ET-70 RF-rim, 6 holes, BKT or (WH0) Without wheels |
Traffic Requirements | Off-road use or (TK) Road traffic kit (number plate holder frame with LED-s, wheel stoppers) |
Brakes | (B0) Without brakes or (B1) Hydraulic brakes 2 wheels or (B2) Hydraulic brakes 4 wheels or (B3) Air brakes 2 wheels or (B4) Air brakes 4 wheels or (B1+B3) Pneumatic brakes 2 wheels, hydraulic brakes 2 wheels or (B1-C7) Rückmatic overrun drawbar with B1 hydraulic brakes |
Supply of Hydraulics | Tractor hydraulics or (P1+T2+) Piston pump on the drawbar, 65L @650rpm, Tank, 95L oil-filled with HVLP oil or (P2+T2+) Piston pump on the drawbar, 82L @650rpm, Tank, 95L oil-filled with HVLP oil |
Control Unit | Without platform or (D1) Platform with back support on the drawbar (PSH option must be selected for crane) or (D2) Platform with back support for trailer with overrun front brakes |
Biomass Box | (Bbox) Yes or No Biomass box |
Bolt | Not applicable (with drawbar C1) or (K1) Bolt on turning eye 50mm (100x110) only if C2 or C3 drawbar have been chosen or (K2) Bolt on fixed eye 40mm (100x110) only if C2 or C3 drawbar have been chosen or (K3) Bolt on K-80 eye (100x110) only if C2 or C3 drawbar have been chosen |
LED Lights | No Lights or (L2) Rear LED lights Kilpi with flexible arm, reflectors |
