FT11 Trailer (M26)

FT11 Trailer (M26)

Sturdy forest trailer for heavy-duty users. Permissible gross weight 14.000kg and loading area 2,5 m2 ensures efficiency. Cranes with gross lifting moment from 60 to 76 kNm are designed for this trailer. Steering drawbar is operated with 2 cylinders.

9 636,00 €

Cargo Module
- (A3+BL) Bolsters 3 pairs + bolster lock
- (A4+BL) Bolsters 4 pairs + bolster lock + 545,00 €
- (A4Ex+BL) Frame extension, bolsters 4 pairs+bolster lock + 1 007,00 €
Drawbar
- (C2) German high
- (C3) Austrian low
Hitch
- (K1) Bolted, swivelling D50 (100x110) + 182,00 €
- (K1.1) Bolted HD, swiveling D50 (110x100) + 297,00 €
- (K2) Bolted, fixed D40 (100x110)
- (K3) Bolted K-80 (100x110) + 314,00 €
Drive
- (RWD0) Without drive
- (RWD) Roller-drive, tractor hydraulic + 4 703,00 €
- (RWD+) Roller-drive with elect. control system + 6 955,00 €
- (25WDF) Front 2WD BB250 el. control + 13 800,00 €
- (25WDR) Rear 2WD BB250 el. control + 13 800,00 €
Brakes
- (B0) unbraked
- (B1) Hydraulic, 2 hubs + 941,00 €
- (B2) Hydraulic, 4 hubs + 1 815,00 €
- (B3) Air, 2 hubs + 1 568,00 €
- (B4) Air, 4 hubs + 2 632,00 €
- (B1+B3) Air, 2 hubs + hydraulic, 2 hubs
Parking brake
- No
- (PB1) Actuators at wheels + 132,00 €
Hydraulic supply
- Tractor hydraulics
- (P1+T2+) Piston pump on the drawbar, 65L @650rpm, Tank, 95L oil-filled with HVLP oil + 2 393,00 €
- (P2+T2+) Piston pump on the drawbar, 82L @650rpm, Tank, 95L oil-filled with HVLP oil + 2 838,00 €
- (P4+T2+) Piston pump with multiplier on the drawbar, 98L @650rpm, Tank, 95L oil-filled with HVLP oil + 3 284,00 €
- (P6+T2+) Load sensing pump with multiplier on the drawbar, 120L @650rpm, Tank, 95L oil-filled with HVLP oil + 5 544,00 €
- (P4PTO+T2+) Piston pump with female-multiplier to PTO, 98L @650rpm, Tank, 95L oil-filled with HVLP oil + 3 251,00 €
- (P6PTO+T2+) Load sensing pump with female-multiplier to PTO, 98L @650rpm, Tank, 95L oil-filled with HVLP oil + 5 544,00 €
Oil cooling package
- (CP0) No
- (CP2) Yes, on T2 or T2+ + 1 023,00 €
Operator platform
- (D0) No platform
- (D1) Platform with back support + 545,00 €
Wheels
- (WH0) w/o wheels
- (WH3.6) 500/50-17 RF-rim, 6 holes + 2 492,00 €
- (WH5.6) 400/55-22,5 RF-rim, 6 holes + 3 234,00 €
- (WH6.8) 550/45-22,5 RF-rim, 8 holes + 3 779,00 €
- (WH8.8) 500/45-22,5 RF-rim, 8 holes + 3 993,00 €

This combination does not exist.
