• Cargo Module

  • (A3) Bolster 3 pairs
  • (A4) Bolster 4 pairs + 413,00 €
  • (A4Ex+BL) Frame extension, bolsters 4 pairs+bolster lock + 726,00 €

• Drawbar

  • (C1) Scandinavian low
  • (C2) German high
  • (C3) Austrian low
  • (C7) High type Rückmatic overrun + 594,00 €

• Hitch

  • Welded swivelling
  • (K1) Bolted, swivelling D50 (100x110) + 289,00 €
  • (K2) Bolted, fixed D40 (100x110) + 124,00 €
  • (K3) Bolted K-80 (100x110) + 363,00 €
  • Fixed

• Brakes

  • (B0) unbraked
  • (B1) Hydraulic, 2 hubs + 941,00 €
  • (B2) Hydraulic, 4 hubs + 1 815,00 €
  • (B3) Air, 2 hubs + 1 568,00 €
  • (B4) Air, 4 hubs + 2 632,00 €
  • (B1+B3) Air, 2 hubs + hydraulic, 2 hubs
  • (B0-C7) Rückmatic overrun brakes on 2 hubs + 1 155,00 €
  • (B1-C7) Rückmatic overrun brakes, 2 hubs + hydraulic, 2 hubs + 2 096,00 €

• Parking brake

  • No
  • (PB1) Actuators at wheels + 285,00 €

• Hydraulic supply

  • Tractor hydraulics
  • (P7+T1+) Piston pump on drawbar, 50L/min@650rpm, tank 40L HVPL32 oil + 1 865,00 €
  • (P1+T2+) Piston pump on the drawbar, 65L @650rpm, Tank, 95L oil-filled with HVLP oil + 2 393,00 €
  • (P2+T2+) Piston pump on the drawbar, 82L @650rpm, Tank, 95L oil-filled with HVLP oil + 2 838,00 €

• Operator platform

  • (D0) No platform
  • (D1) Platform with back support + 545,00 €
  • (D2) Platform with back support (C7) + 545,00 €

• Wheels

  • (WH0) w/o wheels
  • (WH2.6) 400/60-15,5 std. rim, 6 holes + 1 436,00 €
  • (WH3.6) 500/50-17 RF-rim, 6 holes + 2 492,00 €
  • (WH4.6) 480/45-17 RF-rim, 6 holes + 2 303,00 €

This combination does not exist.
